Our in-house developed ProSpector® is powerful and flexible to perform a range of pipeline and cable inspection tasks underwater. Smaller in comparison to larger more traditional Inspection ROV's, yet with a better operational capability. It has the advantage of built-in MCS Photo Realistic 3D Cloud (PRC) technology for highly accurate subsea measurements.
Specifications
_
Power / Vehicle Cameras:
| Propulsion: | 70 KW |
| Maneuverability: | 6 D.O.F |
| Thrusters: |
|
| Camera 1: | 1x colored FHD PAN/Tilt/Zoom camera |
| Camera 2: | 360 Deg. fixed array of cameras |
| Camera 3: |
4x HD Cameras (Extendable) |
| 3D Image Scan: |
|
| Light System: |
8x Distributed LED light system |
Vehicle Weight/Dimensions/Depth:
| Weight in air: | 450 Kg |
| Dimensions LxWxH: | 2100 x 1300 x 500 mm |
| Depth Rating: | 300 msw |
| Payload: | 40 Kg |
Capabilities
_
Features:
- Capable of working in high currents and harsh environments.
- Tethered controlled vehicle from either RSV or surface deployed.
- 8 x vertical and horizontal thrusters.
- Max depth rating 300m with future deepwater capability
- Operates at current speeds of up to 6 Knots.
- Payload up to 40Kg.
- Semi-autonomous and can be pre-programmed for remote control.
- Maneuverability with auto heading, depth, pitch and roll functions.
Sensors and Tooling:
- 2x 5-Function Manipulator
- Cathodic Protection Probe
- Ultrasonic Thickness Reading (UT)
- Flooded member detection
- Super Seaking Bathymetric / DFP
- 3D Blue View sonar
- 2D Imaging Sonar
- Brush Cleaning Tool
- Pipe Tracker
Benefits
_
Reduced cost
Reduce costs by performing from a platform or smaller vessel with reduced personnel.
Increased accuracy
High levels of accuracy and 3D PRC technology gathers precise information for planning, construction, and maintenance.
Champion sustainability
Reduce carbon Footprint by eliminating or reducing the need for offshore ROV vessels.
Tailored for pipeline and cable inspection and metrology.
